1810B - Savoie (Marker-lighting)

Application

  • Indicator lighting
  • Marker-lighting

Mounting type

  • Wall lights

Features

Options of luminous effects

  • Non adjustable
  • Inclined beam
  • Paralell beam
  • Transparent flat window

Power supply - Control

  • Cable length
    1 m
  • Integrated
    24V-PWM
    Remote
    24V-0/10V
    ,
    24V-DMX
    ,
    24V-DALI
  • Integrated
    230V-Non dimmable

Material

  • Vandalism-proof, UV-proof, polycarbonate window

Mechanical strength - Waterproofness

  • IP69K pressure water spray (previous registration)
  • Certified in compliance with European Standards 60598-2-22 for emergency lighting units
  • Resists impacts up to 40 joules (IK10)
    40
  • IP67 Tight for temporary immersion
    67

Select your specific requirements with our product configurator, by filtering technical criteria. Download the configurated product datasheet.

  • Electricity consumption
  • Output
  • Maximum use temperature
  • Contact temperature
Configure now
Close
Product configurator
Technical data is subject to changes.
Luminaire guaranteed 5 years.
Luminaire designed and manufactured in France. Made in france

Fitted with a connecting box with one or two cable glands for in-line connection.

  • Organic glass lens
  • Stainless steel mirror back
  • Aerodynamic shape to reduce particle deposits and permit easy cleaning with water.
  • Materials unaffected by corrosive atmosphere in tunnels
  • Beams angled 45°
  • Fireproof safety cable CR1-C1 optional
