1830K - Lucerne (Outdoor lighting)

Application

  • Lighting
  • Outdoor lighting
  • This value is gained from the optimum output of the LED number, inclusive of optic, for a cool white LED (6000K)
    Standard flux :
    892 lm

Mounting type

  • Ground recessed fittings

Features

  • Weight
    525 gr

Options of luminous effects

  • RGBW option
  • Adjustable on 1 axis
  • Transparent flat window
  • Colour control system (optional)

Power supply - Control

  • Cable length
    1 m
  • 24V-PWM 24V
    Integrated
    24V-PWM
    Remote
    24V-0/10V
    ,
    24V-DMX
    ,
    24V-DALI

Material

  • Anodised glazed aluminium
  • 316L Stainless steel
  • Vandalism-proof, scratch-proof, UV-proof, polycarbonate window, M2

Mechanical strength - Waterproofness

  • Resists impacts up to 20 joules (IK10)
    20
  • IP68 Tight for extended immersion
    68

Select your specific requirements with our product configurator, by filtering technical criteria. Download the configurated product datasheet.

  • Electricity consumption
  • Output
  • Maximum use temperature
  • Contact temperature
Configure now
Close
Product configurator
RGBW option available, please contact us.
... Ajax content

Optic options available for the product: 1830K Lucerne

Your search criteria : Number of LEDs : Type of LEDs : Colour :
Select the tab of your choice and click on your chosen optic, then confirm.
Access the photometric data
Close
Photometric data
RGBW option available, please contact us.
... Ajax content

Optic options available for the product: 1830K Lucerne

Your search criteria : Number of LEDs : Type of LEDs : Colour :
Select the tab of your choice and click on one or more chosen optics, then confirm.
Technical data is subject to changes.
Luminaire guaranteed 5 years.
Luminaire designed and manufactured in France. Made in france

Projector equipped with a stainless steel flange of Ø 120 mm with a 3 mm thick protusion.
The flange hides recess plate imperfections.
This projector 1830K does not withstand occassional vehicles driving.

  • Anodised aluminium body
  • Vandalproof organic glass window
  • 316L Stainless steel screws
  • Flush-recessed (except 1830K and 1830D)
  • Withstands occasional traffic from all kinds of vehicles (except 1830K)
  • RGBW options available
